Zebra ZT600 Series Industrial Printers
THE NEXT GENERATION XI SERIES, NOW WITH MORE INTELLIGENCE AND INDUSTRIAL BRAWN
The ZT600 Series advances the legacy of the Xi Series printers to combine rugged durability and exceptional performance on a user-friendly, future-ready platform. These next-generation workhorses are designed to help you navigate the rapidly evolving business landscape. So, whether you’re concerned about growing production line demands, increasing operational complexities, integrating disparate systems or controlling investment costs, the ZT600 Series industrial printers have you covered today – and for years to come.
Request for quotation for:
Zebra ZT600 Series Industrial Printers
- Description
- Specifications
- Video
Description
EXCEPTIONAL PERFORMANCE FROM MICRO LABELS TO HIGH-VOLUME SHIPPING
Boost your productivity with printers that just won’t quit. The ZT600 Series features durable steel structural components that can withstand years of abuse in extreme temperatures, dust, debris and other challenging industrial conditions. Meticulously engineered printing mechanisms provide 24/7 reliability to meet your high-volume production needs. Plus, the ZT610™ offers best-in-class print registration with 600 dpi micro consistent printing.
HASSLE-FREE SETUP, DAILY USE, MAINTENANCE AND TROUBLESHOOTING
Every detail of the ZT600 Series was designed to be user friendly. A standard colour LCD screen or optional 4.3-inch full-colour touch display, along with easy-adjust printhead pressure toggles, make it easy to setup, quickly adjust printer settings and solve issues. Side-loading capabilities and colour-illuminated media and ribbon paths make media changes fast and simple. Onboard sensors, diagnostics and help resources reduce the need for technical support. And guided instructions and feedback prevent common errors and reduce manual adjustments for highly consistent printing.
OPERATIONAL VISIBILITY, REMOTE MANAGEMENT AND FUTURE-READY ADAPTABILITY
The ZT610 and ZT620 are as smart as they are powerful. Zebra’s cloud-accessible Link-OS™ software platform and managed services offerings give you total visibility and control over your printing systems, whether you’re on-site or across the globe. Plus, with two available communication slots, field-installable RFID encoder and media-handling options, and two USB host ports for plug-and-play integration, it’s easy to stay ahead of your evolving business and technology needs, whatever they may be.
Feature Comparison
| Maximum Print Width |
ZT610: 4.09"/104 mm ZT620: 6.6"/168 mm |
| Maximum Print Speed |
ZT610: 14 ips/356 mm per second at 203 dpi 12 ips/305 mm per second at 300 dpi 6 ips/152 mm per second at 600 dpi ZT620: 12 ips/305 mm per second at 203 dpi 8 ips/200 mm per second at 300 dpi |
| Print Resolution (dpi) |
203 dpi/8 dots per mm 300 dpi/12 dots per mm (optional) 600 dpi/24 dots per mm (optional for ZT610 only) |
Standard Features
|
Printer Specifications
| Operating System | Link-OS® |
| Resolution |
203 dpi/8 dots per mm |
| Memory |
1 GB RAM memory |
| Maximum Print Width |
ZT610: 4.09"/104 mm |
| Maximum Print Speed |
ZT610: 14 ips/356 mm per second |
| Media Sensors | Dual media sensors: transmissive and reflective |
| Maximum Continuous Print Length |
ZT610 ZT620 |
Media Characteristics
| Media Width |
ZT610: 0.79"/20 mm to 4.5"/114 mm |
| Maximum Media Roll Size |
8.0"/203 mm O.D. on a 3"/76 mm I.D. core |
| Thickness | 0.0023"/0.058 mm to 0.010"/0.25 mm |
| Media Types | Continuous, die-cut, notch, black-mark |
Ribbon Characteristics
| Standard Length | 1476'/450 m |
| Width |
ZT610: 0.79"/20 mm to 4.33"/110 mm |
| Core | 1.0"/25.4 mm I.D. |
Operating Characteristics
| Environmental |
Operating Temperature: Operating Humidity: 20% to 85% non-condensing Storage/Transportation Temperature: -22F to 140F/ Storage Humidity: 20% to 85% non-condensing |
| Electrical |
Auto-detectable (PFC Compliant) 90-265 VAC, 47-63Hz, rated at 250 Watts ENERGY STAR qualified |
| Agency Approvals |
IEC 60950, EN 55022 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3 cTUVus, CE Marking, FCC-B, ICES-003, VCCI, C-Tick, NOM, S-Mark (Arg), CCC, CU, BSMI, KCC, SABS, IN-Metro |
Physical Characteristics
| ZT610 closed | |
| Length | 19.88"/505 mm |
| Width | 10.56"/268.2 mm |
| Height | 15.58"/395.68 mm |
| Weight | 50 lbs/22.7 kg |
| ZT620 closed | |
| Length | 19.88"/505 mm |
| Width | 13.44"/341.45 mm |
| Height | 15.58"/395.68 mm |
| Weight | 57.4 lbs/26 kg |
Barcode Symbologies
| Linear Barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar, Planet Code 2D Barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39, MicroPDF, RSS-14 (and composite), Aztec |
Fonts and Graphics
| 16 resident expandable ZPL II bitmap and two resident scalable ZPL fonts Asian and other international scalable and smooth bitmapped fonts Unicode™: For multi-language printing Downloadable objects include graphics, scalable and bitmap fonts, label templates and formats IBM Code Page 850 international character sets are available in the fonts A, B, C, D, E, F, G and 0 through software control Code Page 1250, 1252, 1253, 1254, 1255 Support with font 0 32 MB user available DRAM 512 MB user available on-board Flash |
Options and Accessories
|
Connectivity • Two open communication slots to add internal cards for 802.11ac, parallel, Ethernet, and applicator interface. IPv6 option is available as an external dongle attached to a parallel port Media Handling • Rewind: Internally rewinds a full roll of printed labels on 3" core, or peels and rewinds liner • Cutter: Front-mount guillotine cutter and catch tray • Ink-side in ribbon supply spindle RFID • Supports tags compatible with: UHF EPC Gen 2 V2, ISO/IEC 18000-63 and RAIN RFID protocols • Integrated RFID system is user-upgradable in the field and available on both 4" and 6" models • Adaptive Encoding Technology automatically selects optimum encode settings Display • Brightly lit, 4.3-inch full-color touch display with clear navigation and immediate status visibility and support Keyboard Display Unit • ZKDU™ keyboard display units for stand-alone printing applications |
