Description

Perfectly engineered for comfort

Crisp, sharp image quality
Developed in collaboration with Six15 Technologies,
a leader in innovation in wearable optical displays,
the HD4000 offers best-in-class see-through display
technology. You get unmatched color, contrast and
image clarity. And the focal distance is optimized for
head-mounted applications, minimizing eye fatigue.

So light your workers will forget they are wearing glasses
The HD4000 integrates only those components
required to deliver augmented reality functionality —
a display, camera, head tracker and microphone —
there’s no battery, processor or WiFi or cellular
radio required. At less than 1.06 oz./30 g, the
HD4000 is significantly lighter than any other
enterprise wearable display on the market. Your
workers will barely feel these feather-light glasses,
ensuring all-day comfort without fatigue.

Ready for your most demanding enterprise environments

Drop-proof, dust-proof and waterproof
Finally, a wearable display that matches the rugged
design of your Zebra mobile computer. With IP67
sealing, the HD4000 is virtually impervious to
dust and can survive a hose down and complete
immersion in water. And with a 5 ft./1. m drop
specification, you get reliable operation, despite
inevitable everyday drops.

Flexible design to fit practically every worker
The fully adjustable frame mount accommodates left
and right eye use, a wide range of inter-pupillary
distance positioning, as well as prescription glasses.
And you can change the HD4000 from right eye to left
eye in seconds. The result? No eye strain and an all-day
comfortable viewing experience for all of your workers.

Remove from your view in a split second
If the display is distracting a worker during a
conversation with a supervisor or co-worker — or
preventing the visibility required in a dangerous
situation — workers can simply flip it up and out of view.

Hygienic design made for sharing
The HD4000 mounts to commercial, off-the-shelf safety
glasses — no tools required. So you can give each
worker their own personal pair of glasses, improving
hygiene and helping prevent the spread of germs.

Fast deployment — and easy application integration

No batteries required
Just connect the HD4000 with your Zebra host
mobile computer via the proper cable to provide
needed power. Since the HD4000 uses less than
one watt, there is little impact on the host mobile
device battery. And since the host mobile device
batteries are hot-swappable, the mobile device and
the HD4000 can serve your workers around-the-clock.

Simple accessory architecture for maximum functionality and minimum weight
The HD4000 utilizes the enterprise-class battery,
processor and WiFi or cellular radio in the host Zebra
mobile device via its USB 2.0 cable. You enjoy maximum
battery power and battery cycle times, maximum
processing power, plus dependable and fast WiFi or
cellular connections, all delivered via the Zebra mobile
devices you already own. The result? You can deploy
wearable displays with little impact on IT time and cost.
There are no additional batteries to change. No additional
battery pools to manage. No integrated wireless radios to
configure and certify on your network. And no operating
system (OS) updates and version control required.

Simple and robust application support
The Android HD4000 SDK supports many standard
interfaces, simplifying the development of customized
applications that present the pertinent, contextual
information workers need to perform the best next step.
You can use the HD4000 display as a second screen
via Android presentation mode. To simplify integration
in the warehouse, we provide ready-to-use Zebra
Warehouse Templates for fast and simple integration
with leading Warehouse Management System (WMS)
applications. And ready-to-use Application
Programming Interfaces (APIs) make it easy to
integrate with applications in any vertical market.

Display Characteristics

Display Full color OLED / 640 x 400 pixels

Field of View 20.3° diagonal

Eye Box 7.5 mm x 9 mm

Eye Relief 18 mm

Brightness 300 cd/m2

Sensor Characteristics

Camera 5 MP, fixed focus

Head Tracker 9-axis integrated sensor

Audio Integrated microphone

System Characteristics

Connectivity USB 2.0

Host Device Connectivity Android (5.0 and higher) and Windows 10

Frame ESS Crosshair ONE Frame (ANSI Z87.1+)

Physical Characteristics

Weight (without cable) <1.06 oz./<30g Rugged Characteristics

Sealing IP67 (waterproof and dustproof)

Drop Specification 5 ft./1.5 m (to concrete)

Operating Temperature
-4° F to 122° F
-20° C to 50° C
